Description
Specifications
Intervention threshold: 11.9V
Counting time: 30 seconds
Receiver and remote control frequency: 433.9 MHz
Characteristics
Continuous operating current: 200 A
- Short-term operating current: 1000 A for 5 seconds
- Operating temperature: - 30° + 85° C°
Current consumption in operation: < 15 mA
- Current consumption with battery disconnected: < 5 mA
- 12 volt operating range: 8 – 18 volts
- Operating range 24 volts: 13 – 32 volts
- Degree of protection: IP 444
- Contacts: Silver-plated copper
Warning
- Waiting time for reset: 3 seconds from disconnection
- The OFF position disables the operation of the Drive Tech M.
- To reset it, return it to the ON position and restart the vehicle.
- Make sure the connection is correct, especially the GROUND connection.
